HC-5A / HC-5AM
HC-5A
Auto Edge Guide Controller
HC-5AM
Auto/Manual Edge Guide Controller
** The specification HC-5AM is same as HC-5A but with manual control.
Features :
- Low heat generation during operation.
- High airflow capacity for effective removal of dust and debris, helping keep air passages clean and clear.
- Compatible with a wide range of materials.
- Responsive operation with high precision.
- Durable design for long-lasting performance
Driving :
- Motor : 1/2HP, 4P 220/380/440 3 phase 50/6oHZ
- Pump capacity: 3L/min
- Oil tank : 5A-20L
- Hydraulic pressure : 15kg/cm2
- Oil : CPC RL68 / SHF 32
- Temperature : -10°C~+60°C
- Oil cylinder: Φ40, 300 mm (option)
Sensor :
- Fluidic : Air
- Air pressure : 200 mmH2O
- Air capacity : 60 L/min.
- Small: material max thickness : 10mm (standard)
- Large: material thickness : 10-30 mm
Function :
- Cylinder press : 180kg (Φ40 cylinder)
- Operating speed : 30 mm/sec (Unload)
- Accuracy : 0.1mm
- Sensitivity: 0.3sec
Other :
- Weight : 5A-45 kg, (without cylinder)
- Installation : horizontal
