LOAD CELL HS-1125 AXIAL TYPE

Features:

• High-precision design supplied in matched pairs, eliminating the need for compensation adjustments.
• Axial-type design minimizes the influence of roller weight on measurement accuracy.
• Easy and flexible installation.
• Available in flange, pedestal, inner-mounting, and outer-mounting configurations.
• Equipped with a surface-mounted strain gauge for speed measurement.
• Wide measuring range with a ratio of 1:25.
• Compatible with HS-808 and HS-802 tension controllers.
