HC-HE / HC-HEI

Auto/Manual Photo Electric Edge Guide Controller

** The model HC-HEI is avaiable. HE-HEI is same as HC-HE but without manual control.

Features :

• Reliable detection performance, unaffected by ambient light interference.
• Resistant to dust and lint accumulation for consistent detection.
• Capable of detecting objects of various colors.
• Low-maintenance design with high reliability and long service life.

Driving :

• Motor : 1/2HP, 4P 220/380/440 3 phase 50/6oHZ
• Pump capacity: 3L/min
• Oil tank : 15L
• Hydraulic pressure : 15kg/cm2
• Oil : CPC RL68 / SHF 32
• Temperature : -10°C~+60°C
• Oil cylinder: Φ40, 300 mm (option)

Sensor :

• Optical : HEI
• Controller voltage : AC220V
• Small : material max thickness : 15mm (standard)
• Large : material thickness : 16-30mm (option)

Function :

• Cylinder press : 180kg (Φ40 cylinder)
• Operating speed : 30 mm/sec (Unload)
• Precision : 0.2mm

Other :

• Weight : 40kg
• Installation : horizontal
